LT16M Datasheet Overview

The LT16M datasheet outlines the capabilities of LogicTerm Inc.’s flagship mixed-signal test and debug station. Designed for embedded systems engineers, educators, and developers, the LT16M integrates multiple lab instruments into a single compact device—combining a logic analyzer, pattern generator, oscilloscope, programmable power supply, and automation engine.

Key sections include:

  • Hardware Overview: Details on digital I/O, analog channels, power rails, and user interface elements.
  • Software (LTStudio IDE): A Windows-based environment for pattern editing, Python scripting, and batch automation.
  • Programming Architecture: Dual-level execution model combining deterministic hardware patterns with high-level Python services.
  • Data Logging & Analysis: Built-in database views and export options for signal tracking and test results.
  • Practical Examples: Real-world use cases including LED blinking, fault detection, SPI/I2C control, and analog waveform generation.
  • Reference & Troubleshooting: Syntax definitions, database schema, and optimization tips.

The datasheet emphasizes accessibility, automation, and precision—making LT16M a versatile tool for both prototyping and production testing.

Download

LT16M Training Videos

Introduction to LT16M: Next-Generation Mixed-Signal Text & Debug Station.
Getting Started with LT16M: Install LTStudio and USB Drivers.
LTStudio Hello World! Using the pattern generator.
Using batch scripts to generate I-V curves.
LT16M as a Logic Analyzer
LTStudio: Using Digital-to-Analog Converters.
LTStudio: Using Analog-to-Digital Converters.
LTStudio as an Arbitrary Waveform Generator.
LT16M: Generating PWM using Patterns
LT16M: Measuring Duty Cycle using Patterns
